简述：SMP-HU001SMP-HU002SMP-HU003SMP-HU004SMP-HU005SMP-HU006 Battery Parameters
容量范围： 0.64kWh ~ 4.8kWh
电压选项： 12.8V / 25.6V / 48V
电池成分： LiFePO4 (Grade A)
循环寿命： ≥6000 Cycles (@25°C, 80% DOD)
灵 活 性： Supports Series Connection up to 48V/51.2V
防护等级： IP65 (Waterproof & Dustproof)
外形尺寸： Compact, Lightweight Drop-in Lead-Acid Replacement
设计年限： 10 Years
密封的IP65外壳提供全面的防尘和防水保护，非常适合船舶和房车使用。
与重型铅酸电池相比，其重量仅为4.5kg，能量密度提高了3倍，易于操作。
具有智能BMS保护的高级A级LFP电池可提供6000多次深度循环和完全的电气安全。
多功能嵌入式设计，适用于船舶、房车、离网舱室和太阳能储能。
| Battery Parameters | |
|---|---|
| Standard Voltage | 12.8V |
| Nominal Capacity | 50Ah |
| Rated Energy | 0.64kWh |
| Charge-Discharge Current | 25A |
| Working Voltage Range | 10.8 ~ 14.6V |
| Max Charge Voltage | 14.6V |
| Product Dimension | 330 * 172 * 215 mm |
| Package Dimension | 380 * 225 * 281 mm |
| Net Weight | 4.5kg |
| 20GP Container | 882PCS |
| 40HQ Container | 1764PCS |
| Battery Parameters | |
|---|---|
| Standard Voltage | 12.8V |
| Nominal Capacity | 100Ah |
| Rated Energy | 1.28kWh |
| Charge-Discharge Current | 50A |
| Working Voltage Range | 10.8 ~ 14.6V |
| Max Charge Voltage | 14.6V |
| Product Dimension | 330 * 172 * 215 mm |
| Package Dimension | 380 * 225 * 281 mm |
| Net Weight | 10kg |
| 20GP Container | 882PCS |
| 40HQ Container | 1764PCS |
| Battery Parameters | |
|---|---|
| Standard Voltage | 12.8V |
| Nominal Capacity | 150Ah |
| Rated Energy | 1.92kWh |
| Charge-Discharge Current | 50A |
| Working Voltage Range | 10.8 ~ 14.6V |
| Max Charge Voltage | 14.6V |
| Product Dimension | 520 * 217 * 225 mm |
| Package Dimension | 550 * 247 * 265 mm |
| Net Weight | 15kg |
| 20GP Container | 470PCS |
| 40HQ Container | 1088PCS |
| Battery Parameters | |
|---|---|
| Standard Voltage | 12.8V |
| Nominal Capacity | 200Ah |
| Rated Energy | 2.56kWh |
| Charge-Discharge Current | 100A |
| Working Voltage Range | 10.8 ~ 14.6V |
| Max Charge Voltage | 14.6V |
| Product Dimension | 520 * 217 * 225 mm |
| Package Dimension | 550 * 247 * 265 mm |
| Net Weight | 19kg |
| 20GP Container | 470PCS |
| 40HQ Container | 1088PCS |
| Battery Parameters | |
|---|---|
| Standard Voltage | 25.6V |
| Nominal Capacity | 100Ah |
| Rated Energy | 2.56kWh |
| Charge-Discharge Current | 50A |
| Working Voltage Range | 21.6 ~ 29.2V |
| Max Charge Voltage | 29.2V |
| Product Dimension | 520 * 217 * 225 mm |
| Package Dimension | 550 * 247 * 265 mm |
| Net Weight | 19kg |
| 20GP Container | 470PCS |
| 40HQ Container | 1088PCS |
| Battery Parameters | |
|---|---|
| Standard Voltage | 48V |
| Nominal Capacity | 100Ah |
| Rated Energy | 4.8kWh |
| Charge-Discharge Current | 50A |
| Working Voltage Range | 40.5 ~ 54V |
| Max Charge Voltage | 54.75V |
| Product Dimension | 520 * 267 * 220 mm |
| Package Dimension | 570 * 317 * 280 mm |
| Net Weight | 33kg |
| 20GP Container | 470PCS |
| 40HQ Container | 702PCS |
| System & Performance | |
|---|---|
| Cycle Life | ≥ 6000 @ 25°C, 80% DOD |
| Working Temperature | 0 ~ 50°C |
| Storage Temperature | -20 ~ 55°C |
| Humidity | ≤ 80% |
| IP Rating | IP65 |
